Laser Engraver Equipment 3D Crystal Laser Inner Engraving Machine

Name: Laser Engraver Equipment 3D Crystal Laser Inner Engraving Machine
Brand: Suntop
Price: 32750 USD

Quality Laser Engraver Equipment 3D Crystal Laser Inner Engraving Machine for sale

Brand Name : Suntop

Model Number : ST-HSGP-4KB

Certification : CE & ISO 9001

Place of Origin : China

MOQ : 1 set

Price : USD32750 - USD35532

Payment Terms : T/T, L/C

Supply Ability : 25 sets per month

Delivery Time : 23 work days

Packaging Details : Packed with plywood wooden case which suitable for sea or air shipping

Laser pumping : semiconductor diode

Laser wavelength : 532nm

Laser frequency : 4KHZ (4000HZ)

Laser power : 3w

Q-mode : Acousto-optic-Q

Maximum engrave speed points : 220000dots / Minute

Maximum marking scope : 300mm * 400mm * 150mm

Resolution : 800DPI -1200DPI

Cooling : air cooling

Application materials : crystal .glass etc

Device input power : AC220V±10% 50-60Hz

Continous working time : 24 hours

Suitable materials : Crystal, glass, hard plastic, acrylic, metal, etc.

Software language : Chinese, English, Portuguess, Russian, etc.

System Control : Windows XP, Windows 7

Software : self reseach software for 3D, 2Ddots cloud, and for control machine

Gross power/noise : 1.5KW / 50db

Lifetime : more than 20,000 hours

Working mode : with high speed scanner+X+Y+Z (5 axis)

Focus diameter/resolution : 0.02nm / 800DPI

Contact Now

Laser Engraver Equipment 3D Crystal Laser Inner Engraving Machine

1, The details introductions of our this 4000HZ 3D crystal laser inner engraving machine

2, Our 3D crystal laser inner engraving machine's advantages

2.1, CE,FCC, FDA approved

2.2, This machine can engraving both 2D and 3D, (depends on your design).

2.3, Our machine good for quantity production.

2.4, With newest generation laser, high speed, the laser source imported from Germany, it's lifetime more than 25000 hours, the Q-swtich imported from U.K, the galvanometer imported from Germany Scanlab, the F-lens imported from Singpore.

2.5, Our machine also good for big size engraving as big as 300*400*150mm (also very suitable for family, friends ..etc).

3, Machine's technical specifications

Style No.	ST-HSGP-4KB
Laser pumping	semiconductor diode
Laser wavelength	532nm
Laser frequency	4KHZ (4000HZ)
Maximum pulse energy	1.2mj
Laser power	3w
Q-mode	Acousto-optic-Q
Pulse width	7ns
Beam quality	m2＜1.5
Maximum engrave speed points	220,000dots / minute
Maximum marking scope	300mm400mm150mm
Laser head	one
Resolution	800DPI -1200DPI
Focal length	100mm
Focus diameter	0.02mm
Cooling	air cooling
Application materials	crystal .glass etc
Device input power	AC220V±10% 50-60Hz
Machine weight	200kg for machine, 260 kg after packing with computer
Machine size	709097cm for machine, 10478125cm after packing

5, Our special after sale services

2 year guarantee period for product quality (man made damaged is excepted).
Lifelong maintenance and spare parts supply .
Free design of fixtures as customers required .
Free training for machines installation and operation from our professional staff .
